产品用途：
它主要用于制冷空调，冷冻冷藏设备，主要起到控制介质流体通断的作用。
技术参数：
型号 | 规格 | 通径 | KV值 | 型号 | 规格 | 通径 | KV值 |
EGBV-6S | 1/4(∅06) | ∅14 | 2.0 | BV-28 | 9/8(∅28) | ∅25 | 52.0 |
EGBV-10S | 3/8(∅10) | ∅14 | 5.7 | BV-35 | 1-3/8(∅35) | ∅32 | 80.9 |
EGBV-12S | 1/2(∅12) | ∅14 | 10.6 | BV-42 | 1-5/8(∅42) | ∅38 | 80.9 |
EGBV-16S | 5/8(∅16) | ∅14 | 14.1 | BV-54 | 2-1/8(∅54) | ∅50 | 80.9 |
EGBV-18S | 3/4(∅19) | ∅19 | 20.4 | BV-67 | 2-5/8(∅67) | ∅50 | 80.9 |
EGBV-22S | 7/8(∅22) | ∅19 | 28.2 | BV-79 | 3-1/8(∅79) | ∅50 | 80.9 |
外形尺寸：
型号 | A | B | C | ∅D | ∅d | E | G | H | 01 | J | K | S | M | 重量 |
EGBV-6S | 72 | 67 | 9 | 6.5 | 16 | 15 | 50 | 22 | 29.5 | 30 | 41.5 | 24 | M4 | 230 |
EGBV-10S | 72 | 67 | 10 | 10.1 | 16 | 15 | 50 | 22 | 29.5 | 30 | 41.5 | 24 | M4 | 245 |
EGBV-12S | 82 | 77 | 12 | 12.8 | 16 | 15 | 60 | 22 | 29.5 | 30 | 41.5 | 24 | M4 | 255 |
EGBV-16S | 82 | 77 | 14 | 16.1 | 16 | 15 | 60 | 22 | 29.5 | 30 | 41.5 | 24 | M4 | 260 |
EGBV-18S | 97 | 93 | 14 | 19.1 | 22 | 20.5 | 67 | 30 | 40.5 | 36 | 46.5 | 24 | M4 | 510 |
EGBV-22S | 97 | 93 | 17 | 22.3 | 22 | 20.5 | 67 | 30 | 40.5 | 36 | 46.5 | 24 | M4 | 520 |
EGBV-28S | 109 | 106 | 20 | 28.7 | 28 | 24 | 76 | 38 | 47.5 | 44 | 55.5 | 30 | M4 | 800 |
EGBV-35S | 128.5 | 126.5 | 25 | 35.2 | 35 | 31.5 | 88 | 48 | 62 | 44 | 71.5 | 34 | M6 | 1550 |
EGBV-42S | 143 | 136 | 29 | 41.5 | 42 | 35 | 98 | 55 | 71 | 56 | 86.5 | 42 | M6 | 2300 |
EGBV-54S | 157 | 148 | 34 | 54.2 | 54 | 46 | 101 | 74 | 91 | 56 | 94.5 | 42 | M6 | 3900 |
EGBV-67 | 157 | 148 | 36 | 67.0 | 54 | 46 | 101 | 74 | 91 | 63 | 94.5 | 42 | M6 | 3950 |
EGBV-79 | 157 | 148 | 40 | 79.6 | 54 | 46 | 101 | 74 | 91 | 63 | 94.5 | 42 | M6 | 4030 |
